AdderLink XD150FX Dual-Link DVI/USB Mutli Mode Fibre Optic Extender with US mains lead
SKU#: XD150FX-MM-US
UPC#:Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.
California Prop 65 Warning
For CA Residents Only.
California Proposition 65 Warning
Proposition 65, officially the Safe Drinking Water and Toxic Enforcement Act of 1986, is a law that requires warnings be provided to California consumers when they might be exposed to chemicals identified by California as causing cancer or reproductive toxicity. The warnings are intended to help California consumers make informed decisions about their exposures to these chemicals from the products they use. The California Office of Environmental Health Hazard Assessment (OEHHA) administers the Proposition 65 program and publishes the listed chemicals, which includes more that 850 chemicals. In August 2016, OEHHA adopted new regulations, effective on August 30, 2018, which change the information required in Proposition 65 warnings.
• WARNING: Some cable, plastic, and metal products may contain chemicals known to the state of CA to cause cancer, birth defects, or other reproductive harm.
For further information, please visit www.P65Warnings.ca.gov
- Description+
- Features+
- Specs+
- Approvals / Compliance
- CE
- FCC
- Hardware compatibility All computers with DVI, USB and audio.
- DVI Interface The system supports resolutions to a maximum of 2560 x 1600 @60Hz.
- USB 2.0 Supports USB 2.0 devices (Low, Full and High Speed). Isochronous devices are supported.
- DVI
- Audio 3.5mm x 2
- USB Type-B
- Options port (6p6c)
- Ethernet port (8p8c)
- DVI
- Audio 3.5mm (line in and out), Audio 3.5mm (mic in and headphones)
- USB Type-A x 4
- Options port (6p6c)
- Materials: Compact case, robust metal construction
- Dimensions: 169mm/6.65" (w), 31mm/1.22" (h), 120mm/4.8" (d)
- Weight: 0.6kg/1.3lbs
- 3 pin locking DC jack (2 x power adapters included)
- 100-240VAC 50/60Hz
- 0.7A, input to the power adapter
- 12VDC 18W output from the power adapter
- Package Contents+
- XD150 local and remote modules
- 2 x locking power supplies
- Video cable DVI-D to DVI-D
- USB cable 2m (a to B)
- Reviews+
- Approvals / Compliance
- CE
- FCC
- Hardware compatibility All computers with DVI, USB and audio.
- DVI Interface The system supports resolutions to a maximum of 2560 x 1600 @60Hz.
- USB 2.0 Supports USB 2.0 devices (Low, Full and High Speed). Isochronous devices are supported.
- DVI
- Audio 3.5mm x 2
- USB Type-B
- Options port (6p6c)
- Ethernet port (8p8c)
- DVI
- Audio 3.5mm (line in and out), Audio 3.5mm (mic in and headphones)
- USB Type-A x 4
- Options port (6p6c)
- Materials: Compact case, robust metal construction
- Dimensions: 169mm/6.65" (w), 31mm/1.22" (h), 120mm/4.8" (d)
- Weight: 0.6kg/1.3lbs
- 3 pin locking DC jack (2 x power adapters included)
- 100-240VAC 50/60Hz
- 0.7A, input to the power adapter
- 12VDC 18W output from the power adapter
- XD150 local and remote modules
- 2 x locking power supplies
- Video cable DVI-D to DVI-D
- USB cable 2m (a to B)
AdderLink Single Mode Fibre KVM Extender (XD150FX)
The ADDERLink XD150FX high-performance KVM (Keyboard, Video, Mouse) transmits high resolution video, USB 2.0 and audio signals up to 4km (2.5miles), Critical computer hardware can be held in a secure, temperature-controlled environment and the XD150FX delivers the same desktop experience through real-time, lossless extension to the user workstation including support for a wide range of USB devices.
Note: This product is only compatible with other Adder branded products
Extension Distances: flexible resolution versus extension distance options, with resolutions up to 2560 x 1600 @60Hz at extension distances of up to 150m (500ft) for OM2 multi-mode fiber, increasing to 4km (2.5miles) with single-mode fiber
Transparent USB 2.0 (Low, Full, High Speed): for a whole range of USB devices including keyboards, mice, tablets, touch screens and mass storage devices, connected via the built-in 4-port USB hub
Bidirectional Analog Audio: line in/out with microphone and headphone support. The unit delivers CD-quality stereo audio (24bit sampling at 96kHz) is available to transfer audio between local and remote
RS232 support: with RTS/CTS flow control. RS232 can be passed between the units to a maximum baud rate 115K2 via the options port. Adder’s Remote Key Switch (RC4) is also supported
Perfect digital video, real time control: uncompressed video extension with every pixel of every frame transferred with zero loss and in real-time
Fiber Extension: SFP cages allow for flexible use of fiber types
Plug and Play: straightforward installation with no need for extra drivers or software
Locking power connectors: locking 3 Pin DC jack with 2 power adaptors included
CD quality analog audio: stereo channel 16bit sampled at 44.1kHz is available to transfer stereo audio from local to remote for Line Out
Intelligent operation, compatibility and future-proofing: EDID (Extended Display Identification Data) allows the true characteristics of the monitor to be passed back to the computer; KVM switch mode for optimal KVM device compatibility; complete system is flash upgradeable from the computer end.
Space-saving rackmount kit: easy-access 19” rack mounting kit with two units per 1U of rack space
REST API Support: REST (Representational State Transfer) API with all functionality allowing interaction from authorized 3rd party control systems
Web interface control: temperature and status are viewable and each function can be individually controlled. Web interface security is by HTTP digest authentication (RFC 2617) with username and password as requested information
Standards
Compatibility
All known operating systems.
Connectors - Local Unit
Transmitter (TX)
Receiver (RX)
Physical
Power
Operating Temperatures
0 to 40ºC / 32 to 104ºF
Mean Time Between Failure (MTBF)
400,000 hours; calculated to Telecordia standard SR-332 issue 4 March 2016 @55ºC/ 131ºF
