j5create 65W GaN USB-C® 3-Port Charger
SKU#: JUP3365
UPC#:847626006302
Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.
California Prop 65 Warning
For CA Residents Only.
California Proposition 65 Warning
Proposition 65, officially the Safe Drinking Water and Toxic Enforcement Act of 1986, is a law that requires warnings be provided to California consumers when they might be exposed to chemicals identified by California as causing cancer or reproductive toxicity. The warnings are intended to help California consumers make informed decisions about their exposures to these chemicals from the products they use. The California Office of Environmental Health Hazard Assessment (OEHHA) administers the Proposition 65 program and publishes the listed chemicals, which includes more that 850 chemicals. In August 2016, OEHHA adopted new regulations, effective on August 30, 2018, which change the information required in Proposition 65 warnings.
• WARNING: Some cable, plastic, and metal products may contain chemicals known to the state of CA to cause cancer, birth defects, or other reproductive harm.
For further information, please visit www.P65Warnings.ca.gov
- Description+
- The most amount of power the charger can provide to a single device is 65W. The maximum combined power output is 65W.
- Features+
- Designed to provide 65W of power in a much smaller size *The combined power output of the 2-port USB-C® power delivery ports and the USB™ Type-A port
- When using both ports simultaneously, the USB-C® ports provide up to 45W And 18W of fast charging
- The USB-A port can provide up to 30W fast charging when charging using only the USB™ Type-A port
- When using 3 ports simultaneously, USB-C® 1 ports provide up to 45W, USB-C® 2 and USB™ Type-A share 5V 3.6A
- Charging USB-C® and USB™ Type-A port simultaneously automatically balances the charging output up to 65W: For more power output
combinations, please check the chart below - Supports fast charging protocol:
- - USB-C®: PD 3.0?PPS?QC™ 2.0?QC™ 3.0?FCP?AFC?AP 2.4?BC1.2
- - USB™ Type-A: QC™ 3.0-Class-B?SCP?AFC?FCP?AP 2.4?BC1.2
- Suitable for mobile phones, tablets, consoles, and notebooks
- Amount of time required for fully charging the following devices
- iPhone® 12: 2 hours fully charged
- iPhone® 12 Pro max: 1 hours 58 min fully charged
- iPhone® 13 Pro max: 2 hours 10 min fully charged
- MacBook Pro® 14”: 1 hours 33 min fully charged
- MacBook Pro® 15”: 1 hours 48 min fully charged
- Surge, overcharging, overcurrent, and overheating protection to ensure safe charging.
- Built-in intelligent IC to automatically identify devices.
- Specs+
- Input: AC 100V~240V ? 50~60Hz ?1.5A (max)
- Usb: USB-C® Female x2, USB™ Type-A Female x1
- Usb-C Output Half:
- 5V/3A?9V/3A?12V/3A?15V/3A?20V/3.25A (65W Max)
- 5V/3A?9V/3A?12V/3A?15V/3A?20V/3.25A (65W Max)
- Usb Type A Output: 5V/4.5A?9V/3A?12V/2.5A (30W Max.)
- Warranty: 2 Year Limited
- Color: White
- Enclosure Type: Plastic
- Operating Temperature: 32 to 104°F (0 ºC ~ +40 ºC)
- Product Depth: (US)30mm/(UK)49.6mm/(EU)29.9(?0.5mm)
- Product Height: (US)56.05mm/(UK)87.7mm/(EU)93.3mm (?0.5mm)
- Product Weight: 108g(US),119g(UK),107g(EU)
- Product Width: (US)49.7mm/(UK)49.7mm/(EU)49.7mm (?0.5mm)
- Package Contents+
- 1 - 65W GaN USB-C® 3-Port Charger
- 1 - Quick Installation Guide (QIG)
- Reviews+
- The most amount of power the charger can provide to a single device is 65W. The maximum combined power output is 65W.
- Designed to provide 65W of power in a much smaller size *The combined power output of the 2-port USB-C® power delivery ports and the USB™ Type-A port
- When using both ports simultaneously, the USB-C® ports provide up to 45W And 18W of fast charging
- The USB-A port can provide up to 30W fast charging when charging using only the USB™ Type-A port
- When using 3 ports simultaneously, USB-C® 1 ports provide up to 45W, USB-C® 2 and USB™ Type-A share 5V 3.6A
- Charging USB-C® and USB™ Type-A port simultaneously automatically balances the charging output up to 65W: For more power output
combinations, please check the chart below - Supports fast charging protocol:
- - USB-C®: PD 3.0?PPS?QC™ 2.0?QC™ 3.0?FCP?AFC?AP 2.4?BC1.2
- - USB™ Type-A: QC™ 3.0-Class-B?SCP?AFC?FCP?AP 2.4?BC1.2
- Suitable for mobile phones, tablets, consoles, and notebooks
- Amount of time required for fully charging the following devices
- iPhone® 12: 2 hours fully charged
- iPhone® 12 Pro max: 1 hours 58 min fully charged
- iPhone® 13 Pro max: 2 hours 10 min fully charged
- MacBook Pro® 14”: 1 hours 33 min fully charged
- MacBook Pro® 15”: 1 hours 48 min fully charged
- Surge, overcharging, overcurrent, and overheating protection to ensure safe charging.
- Built-in intelligent IC to automatically identify devices.
- Input: AC 100V~240V ? 50~60Hz ?1.5A (max)
- Usb: USB-C® Female x2, USB™ Type-A Female x1
- Usb-C Output Half:
- 5V/3A?9V/3A?12V/3A?15V/3A?20V/3.25A (65W Max)
- 5V/3A?9V/3A?12V/3A?15V/3A?20V/3.25A (65W Max)
- Usb Type A Output: 5V/4.5A?9V/3A?12V/2.5A (30W Max.)
- Warranty: 2 Year Limited
- Color: White
- Enclosure Type: Plastic
- Operating Temperature: 32 to 104°F (0 ºC ~ +40 ºC)
- Product Depth: (US)30mm/(UK)49.6mm/(EU)29.9(?0.5mm)
- Product Height: (US)56.05mm/(UK)87.7mm/(EU)93.3mm (?0.5mm)
- Product Weight: 108g(US),119g(UK),107g(EU)
- Product Width: (US)49.7mm/(UK)49.7mm/(EU)49.7mm (?0.5mm)
- 1 - 65W GaN USB-C® 3-Port Charger
- 1 - Quick Installation Guide (QIG)
65W GaN USB-C® 3-Port Charger
The 65W GaN USB-C® 3-Port Charger can simultaneously charge two USB-C® devices and one USB™ Type-A device. The charger uses GaN technology which enables it to deliver a significant amount of power in a small package. The USB-C® ports support Power Delivery 3.0/2.0 technology enabling laptops, tablets, and mobile devices to charge at the fastest rates possible. For the safety of your gadgets, the charger also has surge, overcharging, overcurrent, and overheating protection. It works excellent as a replacement for the original charger that comes with a variety of mobile devices thanks to its higher charging capabilities, broad compatibility, and small size.
Special Notes:
| USB-C® 1 | USB-C® 2 | USB™ Type-A | Total | |
|---|---|---|---|---|
| 1 | PD65W | 65W | ||
| 2 | PD65W | 65W | ||
| 3 | QC™ 30W | 30W | ||
| 4 | PD45W | PD18W | 63W | |
| 5 | PD45W | QC™ 18W | 63W | |
| 6 | 18W (5V / 3.6A) | 18W | ||
| 7 | PD45W | 18W (5V / 3.6A) | 63W | |
Hardware
Physical Specifications
65W GaN USB-C® 3-Port Charger
The 65W GaN USB-C® 3-Port Charger can simultaneously charge two USB-C® devices and one USB™ Type-A device. The charger uses GaN technology which enables it to deliver a significant amount of power in a small package. The USB-C® ports support Power Delivery 3.0/2.0 technology enabling laptops, tablets, and mobile devices to charge at the fastest rates possible. For the safety of your gadgets, the charger also has surge, overcharging, overcurrent, and overheating protection. It works excellent as a replacement for the original charger that comes with a variety of mobile devices thanks to its higher charging capabilities, broad compatibility, and small size.
Special Notes:
| USB-C® 1 | USB-C® 2 | USB™ Type-A | Total | |
|---|---|---|---|---|
| 1 | PD65W | 65W | ||
| 2 | PD65W | 65W | ||
| 3 | QC™ 30W | 30W | ||
| 4 | PD45W | PD18W | 63W | |
| 5 | PD45W | QC™ 18W | 63W | |
| 6 | 18W (5V / 3.6A) | 18W | ||
| 7 | PD45W | 18W (5V / 3.6A) | 63W | |
