Vertical Cable Cat6 Patch Panel - 110 Type, UL
SKU#: 042-376/12
UPC#:845643003755
Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.
California Prop 65 Warning
For CA Residents Only.
California Proposition 65 Warning
Proposition 65, officially the Safe Drinking Water and Toxic Enforcement Act of 1986, is a law that requires warnings be provided to California consumers when they might be exposed to chemicals identified by California as causing cancer or reproductive toxicity. The warnings are intended to help California consumers make informed decisions about their exposures to these chemicals from the products they use. The California Office of Environmental Health Hazard Assessment (OEHHA) administers the Proposition 65 program and publishes the listed chemicals, which includes more that 850 chemicals. In August 2016, OEHHA adopted new regulations, effective on August 30, 2018, which change the information required in Proposition 65 warnings.
• WARNING: Some cable, plastic, and metal products may contain chemicals known to the state of CA to cause cancer, birth defects, or other reproductive harm.
For further information, please visit www.P65Warnings.ca.gov
- Description+
- Features+
- High Density Space Saving Design
- 110 Type Termination
- Constructed of Durable Electrostatic Powder-Coated Steel
- Accommodates Top, Bottom or Side Cable Entry
- Fits standard 19" Racks and Wall Mount Brackets
- 15 year warranty
- Specs+
- Meets TIA/EIA-568B.2/568B.2-1 Cat.6 ISO/IEC 11801 and EN 50173-1 specification
- 19in panel
- Wire Supported: 22AWG To 26AWG
- Insulation Diameter Range: 0.70 to 1.40mm
- 1U Height, Designed to mount to any standard 19" Rack or Cabinet
- Jack Contacts: Phosphor bronze, 50-micron gold plated
- IDC Contacts: Phosphor bronze, 50-micron gold plate over nickel plating
- Flammability: UL 94 VO
- Size: 1.75x19in
- Operating Temperature: -40 to +70 degrees Celsius
- Black electrostatic powder-coated steel
- UL Certification
- TIA/EIA-T568-A & B Wiring configuration
- SPEC SHEET
- Reviews+
- High Density Space Saving Design
- 110 Type Termination
- Constructed of Durable Electrostatic Powder-Coated Steel
- Accommodates Top, Bottom or Side Cable Entry
- Fits standard 19" Racks and Wall Mount Brackets
- 15 year warranty
- Meets TIA/EIA-568B.2/568B.2-1 Cat.6 ISO/IEC 11801 and EN 50173-1 specification
- 19in panel
- Wire Supported: 22AWG To 26AWG
- Insulation Diameter Range: 0.70 to 1.40mm
- 1U Height, Designed to mount to any standard 19" Rack or Cabinet
- Jack Contacts: Phosphor bronze, 50-micron gold plated
- IDC Contacts: Phosphor bronze, 50-micron gold plate over nickel plating
- Flammability: UL 94 VO
- Size: 1.75x19in
- Operating Temperature: -40 to +70 degrees Celsius
- Black electrostatic powder-coated steel
- UL Certification
- TIA/EIA-T568-A & B Wiring configuration
- SPEC SHEET
Vertical Cable's Cat6 Patch Panel is designed to provide amazing performance and cable management. Each Cat6 Patch Panel comes with 110-type termination while meeting and exceeding TIA/EIA-568B.2/568B.2-1 Cat.6 ISO/IEC 11801 hardware specifications.
These patch panels accommodate top, bottom or side cable entry. This leaves plenty of options on being able to get to your cables once you have everything set up. These IT patch panels are also able to handle wire diameters of 22AWG to 26AWG, so you should be able to easily find a wire to fit.
Each patch bay is a high-density 19-inch panel.
Pair these patch panels with FireFold's Cat6 Ethernet Patch Cables to give your network a clean professional look.
Vertical Cable's Cat6 Patch Panel is designed to provide amazing performance and cable management. Each Cat6 Patch Panel comes with 110-type termination while meeting and exceeding TIA/EIA-568B.2/568B.2-1 Cat.6 ISO/IEC 11801 hardware specifications.
These patch panels accommodate top, bottom or side cable entry. This leaves plenty of options on being able to get to your cables once you have everything set up. These IT patch panels are also able to handle wire diameters of 22AWG to 26AWG, so you should be able to easily find a wire to fit.
Each patch bay is a high-density 19-inch panel.
Pair these patch panels with FireFold's Cat6 Ethernet Patch Cables to give your network a clean professional look.
