Zigen HDMI Advanced EDID Manager and Signal Reclocker
Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.
California Prop 65 Warning
For CA Residents Only.
California Proposition 65 Warning
Proposition 65, officially the Safe Drinking Water and Toxic Enforcement Act of 1986, is a law that requires warnings be provided to California consumers when they might be exposed to chemicals identified by California as causing cancer or reproductive toxicity. The warnings are intended to help California consumers make informed decisions about their exposures to these chemicals from the products they use. The California Office of Environmental Health Hazard Assessment (OEHHA) administers the Proposition 65 program and publishes the listed chemicals, which includes more that 850 chemicals. In August 2016, OEHHA adopted new regulations, effective on August 30, 2018, which change the information required in Proposition 65 warnings.
• WARNING: Some cable, plastic, and metal products may contain chemicals known to the state of CA to cause cancer, birth defects, or other reproductive harm.
For further information, please visit www.P65Warnings.ca.gov
- Description+
- Features+
- Prevents Problems Caused by STB/BRP Using Older HDCP Chip Sets
- Instantly Solve Incompatibility Issues of Newer 4K UHD Content
- Full Strength Signal Buffering and Reclocking
- Advanced EDID Manager via Web Interface
- For Professional Systems Integrators Only
- Operation up to 18Gbps
- 3 Year Manufacturer Warranty
- Specs+
- Audio: HDMI In and Out up to Dolby TrueHD and DTS-HD Master, SPDIF up to Dolby Digital and DTS 5.1
- Resolution: Max SMPTE UHD - 4096x2160P60/RGB/4:4:4
- Color Bit Depth: 8-bit, 10-bit, 12-bit & 16-bit Per Pixel
- Certifications: FCC, HDBaseT, CE, RoHS, HDCP, HDMI
- Operating Humidity: 20-90% Non-condensing
- Operating Temperature: 32-122°F (0-50°C)
- Chroma Subsampling: 4:4:4, 4:2:2, 4:2:0
- Audio Sampling Rates: Up to 1536 KHz
- Bandwidth: 18Gbps/sec
- HDCP: 2.2, 1.4 or None
- Color Space: RGB, YUV
- Dimensions: 4 x 3 x 1"
- CEC: Pass Through
- Weight: 0.25 lb.
- USER MANUAL
- Package Contents+
- (1) ZIG-BF HDMI Advanced EDID Manager and Signal Reclocker
- (1) 12V DC Locking Power Supply
- (1) User Manual
- Reviews+
- Prevents Problems Caused by STB/BRP Using Older HDCP Chip Sets
- Instantly Solve Incompatibility Issues of Newer 4K UHD Content
- Full Strength Signal Buffering and Reclocking
- Advanced EDID Manager via Web Interface
- For Professional Systems Integrators Only
- Operation up to 18Gbps
- 3 Year Manufacturer Warranty
- Audio: HDMI In and Out up to Dolby TrueHD and DTS-HD Master, SPDIF up to Dolby Digital and DTS 5.1
- Resolution: Max SMPTE UHD - 4096x2160P60/RGB/4:4:4
- Color Bit Depth: 8-bit, 10-bit, 12-bit & 16-bit Per Pixel
- Certifications: FCC, HDBaseT, CE, RoHS, HDCP, HDMI
- Operating Humidity: 20-90% Non-condensing
- Operating Temperature: 32-122°F (0-50°C)
- Chroma Subsampling: 4:4:4, 4:2:2, 4:2:0
- Audio Sampling Rates: Up to 1536 KHz
- Bandwidth: 18Gbps/sec
- HDCP: 2.2, 1.4 or None
- Color Space: RGB, YUV
- Dimensions: 4 x 3 x 1"
- CEC: Pass Through
- Weight: 0.25 lb.
- USER MANUAL
- (1) ZIG-BF HDMI Advanced EDID Manager and Signal Reclocker
- (1) 12V DC Locking Power Supply
- (1) User Manual
Note: This product has been discontinued.
The Zigen ZIG-BF HDMI Advanced EDID Manager and Signal Reclocker is a systems integrator's best friend when it comes to correcting 4K UHD HDMI issues. This handy device reclocks signals to provide adequate strength to support newer HDCP 2.2 chip sets, which require handshakes of less than 10 milliseconds. It also provides advanced EDID management with 22 presets, plus custom tables.
Note: This product has been discontinued.
The Zigen ZIG-BF HDMI Advanced EDID Manager and Signal Reclocker is a systems integrator's best friend when it comes to correcting 4K UHD HDMI issues. This handy device reclocks signals to provide adequate strength to support newer HDCP 2.2 chip sets, which require handshakes of less than 10 milliseconds. It also provides advanced EDID management with 22 presets, plus custom tables.
