BZBGEAR Universal PTZ NDI/HDMI/SDI/USB 3.0 RS232/485 Live Streaming Camera
SKU#: BG-UPTZ-ND12X-B
UPC#:850023208576
Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.
California Prop 65 Warning
For CA Residents Only.
California Proposition 65 Warning
Proposition 65, officially the Safe Drinking Water and Toxic Enforcement Act of 1986, is a law that requires warnings be provided to California consumers when they might be exposed to chemicals identified by California as causing cancer or reproductive toxicity. The warnings are intended to help California consumers make informed decisions about their exposures to these chemicals from the products they use. The California Office of Environmental Health Hazard Assessment (OEHHA) administers the Proposition 65 program and publishes the listed chemicals, which includes more that 850 chemicals. In August 2016, OEHHA adopted new regulations, effective on August 30, 2018, which change the information required in Proposition 65 warnings.
• WARNING: Some cable, plastic, and metal products may contain chemicals known to the state of CA to cause cancer, birth defects, or other reproductive harm.
For further information, please visit www.P65Warnings.ca.gov
- Description+
- Studio Recordings
- Remote Education and healthcare
- House of Worship
- Sport Events
- Concerts
- Event Businesses
- Doctors
- Pastors
- Features+
- NDI: Adoption of NDI® 4.0 from NewTek
- Zoom: Available in 12x/20x/30x Optical zoom + 10x Digital
- Control: IP, IR, and cascadable RS232/485 (VICSA/Pelco) + 255 preset positions
- Multiple Video Outputs: HDMI, 3G-SDI, USB 3.0, and IP-Streaming working simultaneously
- Latest Streaming Tech: Supports H.264/H.265 video compression and RTMP(S) network protocol for Youtube/Facebook live streaming
- Specs+
- Package Contents+
- 1x BZBGEAR BG-UPTZ-ND Camera
- 1x 12V/1.5A Power supply
- 1x RS232 control cable
- 1x IR Remote Control
- 1x User Manual
- Reviews+
- Studio Recordings
- Remote Education and healthcare
- House of Worship
- Sport Events
- Concerts
- Event Businesses
- Doctors
- Pastors
- NDI: Adoption of NDI® 4.0 from NewTek
- Zoom: Available in 12x/20x/30x Optical zoom + 10x Digital
- Control: IP, IR, and cascadable RS232/485 (VICSA/Pelco) + 255 preset positions
- Multiple Video Outputs: HDMI, 3G-SDI, USB 3.0, and IP-Streaming working simultaneously
- Latest Streaming Tech: Supports H.264/H.265 video compression and RTMP(S) network protocol for Youtube/Facebook live streaming
- 1x BZBGEAR BG-UPTZ-ND Camera
- 1x 12V/1.5A Power supply
- 1x RS232 control cable
- 1x IR Remote Control
- 1x User Manual
BZBGEAR Universal PTZ NDI/HDMI/SDI/USB 3.0 RS232/485 Live Streaming Camera
You spoke – we listened! We have taken our popular UPTZ camera and added NDI|HX functionality to create what we think is the most versatile camera on the market. This all-rounder is ideal for almost any possible application you can imagine. High grade lenses give you pristine image quality. Exceptional mechanical craftsmanship and high-grade components result in responsive and quiet operation. The latest compression algorithms and a diverse array of video outputs provide compatibility with nearly any setup. From video conferencing and tele-education, to broadcasting events and streaming to multiple online platforms – you can do it all with BZBGEAR BG-UPTZ cameras.
Ideal fit for:
Who is buying it?
| SKU | Optical Zoom | Field of View | 3G-SDI | HDMI | USB |
|---|---|---|---|---|---|
| BG-UPTZ-12XHSU (Black, Silver, White) |
12X | 72.5° |  |
|
|
| BG-UPTZ-20XHSU (Black, Silver, White) |
20X | 54.7° | |
|
|
| BG-UPTZ-30XHSU (Black, Silver, White) |
30X | 65.1° | |
|
|
| BG-UPTZ-ND12X | BG-UPTZ-ND20X | BG-UPTZ-ND30X | |
| Lens | 12X Optical zoom | 20X Optical zoom | 30X Optical zoom |
| Horizontal View Angle | 72.5°(W)~6.3°(T) | 54.7°(W)~3.3°(T) | 65.1°(W)~2.34°(T) |
| Image Sensor | 1/2.8" Progressive CMOS | ||
| Effective Pixels | 2.07 Megapixels (16:9) | ||
| Resolution | 1080p60/50, 1080i60/50, 1080p30/25, 720p60/50 | ||
| Interface | USB 3.0, HDMI, 3G-SDI, LAN(POE), RS232/485, LINE IN | ||
| Pan Rotation | 340° (max. speed: 80°/s) | ||
| Tilt Rotation | -30° to +90° (max. speed: 60°/s) | ||
| Focus System | Auto/Manual | ||
| S/N Ratio | ≥50db | ||
| Preset Position | 9 preset positions by IR remote controller, 255 preset positions by Keyboard or PC | ||
| Minimum Illumination | 0.5 Lux (F1.8, AGC ON) | ||
| Exposure Control | Auto/Manual/Priority AE/Exposure Compensation/Bright | ||
| Shutter Speed | 1/1~1/10,000s | ||
| Gain | Auto/Manual | ||
| White Balance | Auto/Manual/ATW/One-click/Indoor/Outdoor | ||
| Image Effect | Full color/black and white/Electronic flip | ||
| Video Output HD | HDMI, 3G-SDI, IP, USB 3.0 | ||
| Control Protocol | RTSP, RTMP, ONVIF, GB/T28181 | ||
| Power | 12V DC | ||
| Power Consumption | Max. 30W (DC 12V) | ||
| Operating Temperature | 0°C~+40°C | ||
| Storage Temperature | -20°C~+60°C | ||
| Camera Dimensions | (L)178 × (W)115.5 × (H)150.9mm | ||
| Weight | 1.38KG | ||
| Color | Black, White | ||
BZBGEAR Universal PTZ NDI/HDMI/SDI/USB 3.0 RS232/485 Live Streaming Camera
You spoke – we listened! We have taken our popular UPTZ camera and added NDI|HX functionality to create what we think is the most versatile camera on the market. This all-rounder is ideal for almost any possible application you can imagine. High grade lenses give you pristine image quality. Exceptional mechanical craftsmanship and high-grade components result in responsive and quiet operation. The latest compression algorithms and a diverse array of video outputs provide compatibility with nearly any setup. From video conferencing and tele-education, to broadcasting events and streaming to multiple online platforms – you can do it all with BZBGEAR BG-UPTZ cameras.
Ideal fit for:
Who is buying it?
| SKU | Optical Zoom | Field of View | 3G-SDI | HDMI | USB |
|---|---|---|---|---|---|
| BG-UPTZ-12XHSU (Black, Silver, White) |
12X | 72.5° | |
|
|
| BG-UPTZ-20XHSU (Black, Silver, White) |
20X | 54.7° | |
|
|
| BG-UPTZ-30XHSU (Black, Silver, White) |
30X | 65.1° | |
|
|
| BG-UPTZ-ND12X | BG-UPTZ-ND20X | BG-UPTZ-ND30X | |
| Lens | 12X Optical zoom | 20X Optical zoom | 30X Optical zoom |
| Horizontal View Angle | 72.5°(W)~6.3°(T) | 54.7°(W)~3.3°(T) | 65.1°(W)~2.34°(T) |
| Image Sensor | 1/2.8" Progressive CMOS | ||
| Effective Pixels | 2.07 Megapixels (16:9) | ||
| Resolution | 1080p60/50, 1080i60/50, 1080p30/25, 720p60/50 | ||
| Interface | USB 3.0, HDMI, 3G-SDI, LAN(POE), RS232/485, LINE IN | ||
| Pan Rotation | 340° (max. speed: 80°/s) | ||
| Tilt Rotation | -30° to +90° (max. speed: 60°/s) | ||
| Focus System | Auto/Manual | ||
| S/N Ratio | ≥50db | ||
| Preset Position | 9 preset positions by IR remote controller, 255 preset positions by Keyboard or PC | ||
| Minimum Illumination | 0.5 Lux (F1.8, AGC ON) | ||
| Exposure Control | Auto/Manual/Priority AE/Exposure Compensation/Bright | ||
| Shutter Speed | 1/1~1/10,000s | ||
| Gain | Auto/Manual | ||
| White Balance | Auto/Manual/ATW/One-click/Indoor/Outdoor | ||
| Image Effect | Full color/black and white/Electronic flip | ||
| Video Output HD | HDMI, 3G-SDI, IP, USB 3.0 | ||
| Control Protocol | RTSP, RTMP, ONVIF, GB/T28181 | ||
| Power | 12V DC | ||
| Power Consumption | Max. 30W (DC 12V) | ||
| Operating Temperature | 0°C~+40°C | ||
| Storage Temperature | -20°C~+60°C | ||
| Camera Dimensions | (L)178 × (W)115.5 × (H)150.9mm | ||
| Weight | 1.38KG | ||
| Color | Black, White | ||
