BZBGEAR 4X1 4K UHD HDMI Seamless Multiviewer/Switcher/Scaler with Audio and RS-232 Support
SKU#: BG-UMV-HA41
UPC#:850023208026
Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.
California Prop 65 Warning
For CA Residents Only.
California Proposition 65 Warning
Proposition 65, officially the Safe Drinking Water and Toxic Enforcement Act of 1986, is a law that requires warnings be provided to California consumers when they might be exposed to chemicals identified by California as causing cancer or reproductive toxicity. The warnings are intended to help California consumers make informed decisions about their exposures to these chemicals from the products they use. The California Office of Environmental Health Hazard Assessment (OEHHA) administers the Proposition 65 program and publishes the listed chemicals, which includes more that 850 chemicals. In August 2016, OEHHA adopted new regulations, effective on August 30, 2018, which change the information required in Proposition 65 warnings.
• WARNING: Some cable, plastic, and metal products may contain chemicals known to the state of CA to cause cancer, birth defects, or other reproductive harm.
For further information, please visit www.P65Warnings.ca.gov
- Description+
- Features+
- Based on FPGA technology
- Upgradeable firmware
- Rack mountable, all metal construction
- SNR > 90dB, 20Hz-20 kHz bandwidth
- Auto-scaling for each source input
- Cascadable for up to 16 screens on 1 display
- Resize the windows with 3 different options
- Single window auto-switching
- 16 pre-defined layouts
- Specs+
- Package Contents+
- 1x BG-UMV-HA41 4K 4X1 Seamless Switcher
- 1x IR Remote
- 4x Plastic Cushions
- 2x Mounting Ears
- 4x Mounting Screws
- 2x 3-pin Terminal Block
- 1x RS232 Cable (3-pin to DB9)
- 1x Power Adapter (24V DC 1.25A)
- 1x User Manual
- Reviews+
- Based on FPGA technology
- Upgradeable firmware
- Rack mountable, all metal construction
- SNR > 90dB, 20Hz-20 kHz bandwidth
- Auto-scaling for each source input
- Cascadable for up to 16 screens on 1 display
- Resize the windows with 3 different options
- Single window auto-switching
- 16 pre-defined layouts
- 1x BG-UMV-HA41 4K 4X1 Seamless Switcher
- 1x IR Remote
- 4x Plastic Cushions
- 2x Mounting Ears
- 4x Mounting Screws
- 2x 3-pin Terminal Block
- 1x RS232 Cable (3-pin to DB9)
- 1x Power Adapter (24V DC 1.25A)
- 1x User Manual
BZBGEAR 4X1 4K UHD HDMI Seamless Multiview Switcher
This 4K multi-view switcher is a great fit for anyone looking to seamlessly flow between presentations and videos on one display, as well as simultaneously view up to four video sources on that display via a single HDMI output. Video sources shown either in full screen or through multi-view windows can be easily swapped with the push of a button from the IR remote and several other helpful control options to monitor multiple video sources at once.
Thanks to its 4K@30 Hz resolution, every detail is captured from each video source. Two audio outputs also support audio de-embedding to extract audio from your sources. Audio embedding options are also available via two inputs on the device.
Connectivity & Control
Integrated auto video scaling for each of the four HDMI inputs ensures video signals from your devices are compatible with 4K displays. Audio embedding is supported with line and mix in dual audio input. Audio de-embedding is supported via the two TOSLINK and 3.5mm outputs.
The BG-UMV-HA41 has several control options, including buttons on the front panel, IR remote control, RS232, and a web interface. The layout and size of each display window can be customized, and users can also choose from 16 preset layouts via the BG-UMV-HA41’s web interface. On the IR remote, there are four presets with four additional slots open for users to set their own presets.
The BG-UMV-HA41 can be easily rack mounted, furthering its flexibility for use in any environment.
High Resolution Inputs
Input Up To 4K@30Hz 4:4:4 Chroma
Control Options
IR remote, RS-232, Web GUI, or Front Panel Buttons
Seamless Switching
Quick And Easy Source Switching
Audio Embedding
3-Pin Line-In And Mix Inputs
Audio De-embedding
3.5mm Analog And TOSLINK Digital Outputs
Multi-View
Simultaneously Display Multiple Inputs On A Single Monitor
BZBGEAR 4X1 4K UHD HDMI Seamless Multiview Switcher
This 4K multi-view switcher is a great fit for anyone looking to seamlessly flow between presentations and videos on one display, as well as simultaneously view up to four video sources on that display via a single HDMI output. Video sources shown either in full screen or through multi-view windows can be easily swapped with the push of a button from the IR remote and several other helpful control options to monitor multiple video sources at once.
Thanks to its 4K@30 Hz resolution, every detail is captured from each video source. Two audio outputs also support audio de-embedding to extract audio from your sources. Audio embedding options are also available via two inputs on the device.
Connectivity & Control
Integrated auto video scaling for each of the four HDMI inputs ensures video signals from your devices are compatible with 4K displays. Audio embedding is supported with line and mix in dual audio input. Audio de-embedding is supported via the two TOSLINK and 3.5mm outputs.
The BG-UMV-HA41 has several control options, including buttons on the front panel, IR remote control, RS232, and a web interface. The layout and size of each display window can be customized, and users can also choose from 16 preset layouts via the BG-UMV-HA41’s web interface. On the IR remote, there are four presets with four additional slots open for users to set their own presets.
The BG-UMV-HA41 can be easily rack mounted, furthering its flexibility for use in any environment.
High Resolution Inputs
Input Up To 4K@30Hz 4:4:4 Chroma
Control Options
IR remote, RS-232, Web GUI, or Front Panel Buttons
Seamless Switching
Quick And Easy Source Switching
Audio Embedding
3-Pin Line-In And Mix Inputs
Audio De-embedding
3.5mm Analog And TOSLINK Digital Outputs
Multi-View
Simultaneously Display Multiple Inputs On A Single Monitor
