CommScope PFU-P-A-O-001-01 PoE Extender - Aruba Bracket, Outdoor, 30 Watt, 1-Port 300100113888
SKU#: PFU-P-A-O-001-01
UPC#:
Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.
California Prop 65 Warning
For CA Residents Only.
California Proposition 65 Warning
Proposition 65, officially the Safe Drinking Water and Toxic Enforcement Act of 1986, is a law that requires warnings be provided to California consumers when they might be exposed to chemicals identified by California as causing cancer or reproductive toxicity. The warnings are intended to help California consumers make informed decisions about their exposures to these chemicals from the products they use. The California Office of Environmental Health Hazard Assessment (OEHHA) administers the Proposition 65 program and publishes the listed chemicals, which includes more that 850 chemicals. In August 2016, OEHHA adopted new regulations, effective on August 30, 2018, which change the information required in Proposition 65 warnings.
• WARNING: Some cable, plastic, and metal products may contain chemicals known to the state of CA to cause cancer, birth defects, or other reproductive harm.
For further information, please visit www.P65Warnings.ca.gov
- Description+
- Features+
- Automatically Conditions Electrical Voltage to the Correct Level
- Environmentally Sealed Closure - IP67
- Electrical Power Management
- Circuit Protection Electronics
- Optical to Electrical Media Conversion
- Specs+
- Color: Silver Gray
- Material: Sand Cast
- Weight: 2lb (0.9kg)
- Number of Ports: 1
- Height: 2.717" (69mm)
- Length: 557.743' (170m)
- Width: 4.92" (125mm)
- Transition Performance: 25.5W, PoE+ Rated Output
- Approved Standards: EN 300.019-1-4 Class 4.1E, EN 55022, EN 55024, EN 60950, IEC 60529, IEC 60793-2-10 type A1a.2, ISO/IEC 11801, ITU-T G.657.A2, ITU.T K21, SELV and NEC Class II
- Mounting Type: Aruba Mounting Arm
- Region: Asia | Australia/New Zealand | EMEA | Latin America | North America
- Termination Method: Optical Multimode Input: OM3/OM4 SFP | Optical Singlemode Input: G657.A2 SFP | PoE+ Media Converter Input: Duplex OM3 | PoE+ Media Converter Input: Simplex SMF | RJ45 Connector Output: Half Duplex and Full
- Installation Temperature Range: -5 – 50 °C
- Operating Temperature: -40 – 65 °C
- Storage Temperature: -40 – 70 °C
- Weather Resistant: IP67
- RoHS 2011/65/EU
- USER MANUAL
- BROCHURE
- SPEC SHEET
- SPEC SHEET
- Package Contents+
- (1) PFU-P-A-O-001-01 - for use with the Aruba® Networks mounting bracket
- (2) Aruba Bracket Inserts
- (2) Cable Pass Through
- (2) Seal 'O' Rings
- (2) Seal Caps
- (1) Ethernet Cable Grommet
- (1) Fiber Cable Grommet
- Reviews+
- Automatically Conditions Electrical Voltage to the Correct Level
- Environmentally Sealed Closure - IP67
- Electrical Power Management
- Circuit Protection Electronics
- Optical to Electrical Media Conversion
- Color: Silver Gray
- Material: Sand Cast
- Weight: 2lb (0.9kg)
- Number of Ports: 1
- Height: 2.717" (69mm)
- Length: 557.743' (170m)
- Width: 4.92" (125mm)
- Transition Performance: 25.5W, PoE+ Rated Output
- Approved Standards: EN 300.019-1-4 Class 4.1E, EN 55022, EN 55024, EN 60950, IEC 60529, IEC 60793-2-10 type A1a.2, ISO/IEC 11801, ITU-T G.657.A2, ITU.T K21, SELV and NEC Class II
- Mounting Type: Aruba Mounting Arm
- Region: Asia | Australia/New Zealand | EMEA | Latin America | North America
- Termination Method: Optical Multimode Input: OM3/OM4 SFP | Optical Singlemode Input: G657.A2 SFP | PoE+ Media Converter Input: Duplex OM3 | PoE+ Media Converter Input: Simplex SMF | RJ45 Connector Output: Half Duplex and Full
- Installation Temperature Range: -5 – 50 °C
- Operating Temperature: -40 – 65 °C
- Storage Temperature: -40 – 70 °C
- Weather Resistant: IP67
- RoHS 2011/65/EU
- USER MANUAL
- BROCHURE
- SPEC SHEET
- SPEC SHEET
- (1) PFU-P-A-O-001-01 - for use with the Aruba® Networks mounting bracket
- (2) Aruba Bracket Inserts
- (2) Cable Pass Through
- (2) Seal 'O' Rings
- (2) Seal Caps
- (1) Ethernet Cable Grommet
- (1) Fiber Cable Grommet
NEC Class II requires a power supply unit (PSU) limited to less than 60V DC | PoE standard (IEEE 802.3af) assumes 15.4W power consumption | PoE+ standard (IEEE 802.3at) assumes 25.5W power consumption
NEC Class II requires a power supply unit (PSU) limited to less than 60V DC | PoE standard (IEEE 802.3af) assumes 15.4W power consumption | PoE+ standard (IEEE 802.3at) assumes 25.5W power consumption
