Vertical Cable 1000ft Solid Cat5E Cable - 24AWG 50 Pair 350MHz CMR Bulk Ethernet
Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.
California Prop 65 Warning
For CA Residents Only.
California Proposition 65 Warning
Proposition 65, officially the Safe Drinking Water and Toxic Enforcement Act of 1986, is a law that requires warnings be provided to California consumers when they might be exposed to chemicals identified by California as causing cancer or reproductive toxicity. The warnings are intended to help California consumers make informed decisions about their exposures to these chemicals from the products they use. The California Office of Environmental Health Hazard Assessment (OEHHA) administers the Proposition 65 program and publishes the listed chemicals, which includes more that 850 chemicals. In August 2016, OEHHA adopted new regulations, effective on August 30, 2018, which change the information required in Proposition 65 warnings.
• WARNING: Some cable, plastic, and metal products may contain chemicals known to the state of CA to cause cancer, birth defects, or other reproductive harm.
For further information, please visit www.P65Warnings.ca.gov
- Description+
- Specs+
- Rated Temperature (ºC) 70
- Rated Voltage 30V
- Product Standard Certification CMR
- Application Horizontal Wiring in LAN
- Reference Standard UL Subject 444, EIA/TIA 568B.2 & ISO/IEC 11801
- RoHS Compliant
- ETL listed
- Solid Bare Copper
- Size 24 AWG
- Average Thickness (mm) 0.203
- Min. Point Thickness (mm) 0.195
- Insulation Diameter (±0.005mm) 0.91
- Twisted Pair Diameter (±0.01) 1.82
- Assembly Diameter 10.45
- Flame retardant PVC
- Sequential foot markers on jacket
- Rip Cord under jacket
- Average Thickness (mm) 1.00
- Min. Point Thickness (mm) 0.90
- Outer Diameter (±0.30mm) 12.50
- Pair 1 Blue,White-Blue
- Pair 2 Orange,White-Orange
- Pair 3 Green,White-Green
- Pair 4 Brown,White-Brown
- Test Object: Jacket
- Test Material: Flame Retardant PVC
- Before Tensile Strength (Mpa) >=13.8
- Aging Elongation (%) >=100
- Aging Condition (ºCxhrs) 100x168
- After Tensile Strength (Mpa) >=85% of unaged
- Aging Elongation (%) >=50% of unaged
- Cold Bend (-20±2º Cx4hrs) No Crack
- Reviews+
- Rated Temperature (ºC) 70
- Rated Voltage 30V
- Product Standard Certification CMR
- Application Horizontal Wiring in LAN
- Reference Standard UL Subject 444, EIA/TIA 568B.2 & ISO/IEC 11801
- RoHS Compliant
- ETL listed
- Solid Bare Copper
- Size 24 AWG
- Average Thickness (mm) 0.203
- Min. Point Thickness (mm) 0.195
- Insulation Diameter (±0.005mm) 0.91
- Twisted Pair Diameter (±0.01) 1.82
- Assembly Diameter 10.45
- Flame retardant PVC
- Sequential foot markers on jacket
- Rip Cord under jacket
- Average Thickness (mm) 1.00
- Min. Point Thickness (mm) 0.90
- Outer Diameter (±0.30mm) 12.50
- Pair 1 Blue,White-Blue
- Pair 2 Orange,White-Orange
- Pair 3 Green,White-Green
- Pair 4 Brown,White-Brown
- Test Object: Jacket
- Test Material: Flame Retardant PVC
- Before Tensile Strength (Mpa) >=13.8
- Aging Elongation (%) >=100
- Aging Condition (ºCxhrs) 100x168
- After Tensile Strength (Mpa) >=85% of unaged
- Aging Elongation (%) >=50% of unaged
- Cold Bend (-20±2º Cx4hrs) No Crack
Cat5E Bulk Cable - Vertical Cable In 1000ft 24AWG 50 Pair
A must-have for the most strenuous cable runs. Save time and money on installations where several terminations are needed, with the Cat5E 1000' Bulk Cable 50 Pair Solid, you'll be able to send several undisturbed data signals to several locations with the ease of a single cable run.
50 Pair:
With 50 Twisted Pairs instead of 4, cable runs where several terminations are needed will be much easier and much more cost and time effective. A single cable drop will provide 10 times the amount of terminations as a standard 4 pair Solid Cat5E drop.
Category 5:
Considered the Industry Standard for most network installations, Category 5 (Cat5E, or Cat5) is a "twisted pair" network cable used for carrying data signals at speeds of up to 350MHz of Bandwidth.
Solid Cable Design
Designed for more straight-forward, simple installtions, this particular style of Solid cable is perfect for most installations where cable runs do not require several bends and twists in the line.
24 AWG
For this particular cable, the gauge is 24 AWG, which is a diameter of about 0.0201 Inches, or 0.511mm. 24AWG is the Industry Standard for any typical network cable installation. American Wire Guage (AWG) is the standardized gauging system for measuring wire sizes.
- Conductor
- Insulation
- Jacket
- Color of Pairs
- Mechanical Characteristics
Cat5E Bulk Cable - Vertical Cable In 1000ft 24AWG 50 Pair
A must-have for the most strenuous cable runs. Save time and money on installations where several terminations are needed, with the Cat5E 1000' Bulk Cable 50 Pair Solid, you'll be able to send several undisturbed data signals to several locations with the ease of a single cable run.
50 Pair:
With 50 Twisted Pairs instead of 4, cable runs where several terminations are needed will be much easier and much more cost and time effective. A single cable drop will provide 10 times the amount of terminations as a standard 4 pair Solid Cat5E drop.
Category 5:
Considered the Industry Standard for most network installations, Category 5 (Cat5E, or Cat5) is a "twisted pair" network cable used for carrying data signals at speeds of up to 350MHz of Bandwidth.
Solid Cable Design
Designed for more straight-forward, simple installtions, this particular style of Solid cable is perfect for most installations where cable runs do not require several bends and twists in the line.
24 AWG
For this particular cable, the gauge is 24 AWG, which is a diameter of about 0.0201 Inches, or 0.511mm. 24AWG is the Industry Standard for any typical network cable installation. American Wire Guage (AWG) is the standardized gauging system for measuring wire sizes.
- Conductor
- Insulation
- Jacket
- Color of Pairs
- Mechanical Characteristics
